Electric 3-wheel forklift truck 1.4 - 2.0 t

2020 - 7000 mm
1400 - 2000 kg

Compact electric three-wheel counterbalance forklift trucks with maximum manoeuvrability.
Powerful lift hydraulics for maximum performance even with attachments.
Multifunctional touch display with high user-friendliness.
Ergonomic design and perfect all-round visibility.

EFG 214–220

Our versatile and compact series 2 electric three-wheel counterbalance forklift trucks are the ideal helpers for efficient transport in confined spaces or rear loading and unloading of HGVs. The EFG 2 trucks also impress when used with attachments thanks to their powerful hydraulics. The innovative truck design with its angled B-pillar ensures excellent all-round visibility, while smart assistance systems such as the zoneCONTROL collision protection system or the AI-based addedVIEW person detection increase safety at work. An optimised, ergonomically refined workplace with improved acoustics, enlarged foot-well and a 4.3-inch touch display with redesigned controls promotes focused, fatigue-free working.

Benefits

Connected Trucks

Use the data from your trucks to save time, energy and money and increase efficiency. Our Telematics box (ex factory) provides you with a free fleet management starter package that can be flexibly expanded with various hardware and software components.

Features

Powerful lift hydraulics

Powerful hydraulic performance for maximum throughput when working with attachments.
High lift speeds for fast lifting.

Responsive driving and working behaviour

Mast damping at the mast transitions and soft-stop function at the lower end stop of the forks.
High lift speeds for fast lifting.
Adjustable lever and axle assignment of the controls.

Professional battery management

Proven lead-acid battery technology with maximum reliability and high efficiency.
Battery door for easy battery exchange.
Individual exchange systems using low-lift pallet trucks, stackers or cranes.
Space-saving charging and simple maintenance.
Safe, horizontal transport of the battery unit.

Perfect all-round visibility

Angled B-pillar with a blind spot reduced by up to 65% when reversing.
Optimal view of forks and load thanks to the low-profile design of the side panel.
Optional panorama roof window.

Innovative safety solutions

Standard automatic parking brake to prevent uncontrolled rolling back on ramps and inclines.
Optional SmartStripe LED light strip for increased safety in the warehouse with display of charging progress and other truck conditions.

Optional assistance systems

Pre-operation check for the safety inspection of the truck before starting work.
addedVIEW digital camera systems for improved visibility and safety in demanding operating environments.
zoneCONTROL for monitoring critical warehouse areas and protecting against collisions.
Reduction of travel speed when cornering due to curveCONTROL.
drive / liftCONTROL for automatic reduction of the working speed from a defined lift height.

Adaptable operating concept

Five configurable travel programs including ECO mode.
Three control systems: soloPILOT, duoPILOT and multiPILOT.
Stepless single-point adjustment of the armrest.
Steering column adjustable in height and tilt.
Adjustable lever and axle assignment of the controls.
Single or double pedal operation.

Ergonomic workplace

Noise-optimised truck concept with improved decoupling of the cabin from the chassis and reduced human vibrations.
Enlarged foot-well and optimised steering column for additional knee and legroom.
Low step tread for safe entry and exit.

Multifunctional HMI concept

4.3-inch touch display including EasyAccess Softkey access system to protect against unauthorised use.
Ergonomic keypads on the armrest for comfortable, intuitive operation.
External power supply via optional USB ports in the armrest or the side storage.








Model Overview

Model	Load capacity	Lift height	Travel speed	Overall length	Battery voltage
EFG 214	1,400 kg	7,000 mm	15 km/h	3,036 mm	48 V
EFG 216	1,600 kg	7,000 mm	17 km/h	3,144 mm	48 V
EFG 218	1,800 kg	7,000 mm	17 km/h	3,164 mm	48 V
EFG 220	2,000 kg	7,000 mm	17 km/h	3,164 mm	48 V

Downloads

Factsheet EFG 2 pdf (1.3 MB)

Specsheet EFG 2 pdf (783.3 KB)
